Ray Diagrams Worksheet
Explore the principles of geometric optics through ray diagrams for lenses and mirrors, understanding image formation and characteristics.
Includes
Standards
Topics
Ray Diagrams Worksheet
Name:
Date:
Score:
Read each question carefully and follow the instructions to draw ray diagrams and answer questions about image formation.
1. Which type of lens always produces a virtual, upright, and diminished image?
Convex lens
Concave lens
Plano-convex lens
Double convex lens
2. When an object is placed at the focal point of a concave mirror, where is the image formed?
At the center of curvature
At infinity
Between the focal point and the center of curvature
Behind the mirror
3. The point where parallel rays converge after passing through a convex lens is called the .
4. A mirror has a reflecting surface that bulges outwards.
5. The image formed by a plane mirror is always , virtual, and laterally inverted.
6. A convex mirror can form a real image.
True
False
7. For a convex lens, if the object is placed between F and 2F, the image is formed beyond 2F.
True
False
8. Draw a ray diagram to show the formation of an image by a convex lens when an object is placed beyond 2F. Describe the characteristics of the image formed.
9. Draw a ray diagram to show the formation of an image by a concave mirror when an object is placed between the focal point (F) and the pole (P). Describe the characteristics of the image formed.
Match the optical device with its primary function.
10. Concave Lens
a. Converges parallel rays of light
11. Convex Mirror
b. Diverges parallel rays of light
12. Convex Lens
c. Produces magnified, virtual images for close objects
13. Concave Mirror
d. Always forms virtual, diminished images
